This is the exact guitar you'll receive. This guitar is brand new, but has been on display on our sales floor. May have a few light examples of shop wear such as light marks, scratches, etc. May not ship in original shipping box. This instrument still carries the full manufacturers warranty, and will be thoroughly inspected before shipping.
Weight (Serial Number: MX25154659) - 7lbs 7.5oz
The Jimmie Vaughan Tex-Mex™ Strat® guitar features an alder body, specially shaped tinted maple neck, medium jumbo frets, single-coil Tex-Mex neck and middle pickups, extra hot Tex-Mex bridge pickup, single-ply white pickguard and vintage-style hardware.
General
Series: Artist Signature
Orientation: Right-Hand
Color: Olympic White
Country Of Origin: Mexico
Platform: Artist
Neck
Neck Material: Maple
Neck Finish: Satin Urethane
Neck Shape: Soft "V"
Fingerboard Radius: 9.5" (241 mm)
Fingerboard Material: Maple
Position Inlays: Black Dot
Number of Frets: 21
Truss Rod: Standard
String Nut: Synthetic Bone
Nut Width: 1.650" (42 mm)
Nut Material: Synthetic Bone
Fret Size: Medium Jumbo
Scale Length: 25.5" (648 mm)
Body
Body: Alder
Body Finish: Gloss Polyester
Body Shape: Stratocaster®
Body Material: Alder
Hardware
Bridge: 6-Saddle American Vintage Synchronized Tremolo
Pickguard: 1-Ply White
Control Knobs: White Plastic
Switch Tip: White
Hardware Finish: Chrome
Tuning Machines: Vintage-Style
Strings: Fender® USA 250L Nickel Plated Steel (.009-.042 Gauges), PN 0730250403
Tremolo Arm: American Vintage
Neck Plate: 4-Bolt Vintage-Style
Strap Buttons: American Series
Electronics
Bridge Pickup: Tex-Mex™ "Hot Bridge" Single-Coil Strat®
Middle Pickup: Tex-Mex™ Single-Coil Strat®
Neck Pickup: Tex-Mex™ Single-Coil Strat®
Pickup Configuration: SSS
Controls: Master Volume, Tone 1. (Neck Pickup), Tone 2. (Bridge Pickup)
Switching: 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup
Accessories
Included Accessories: Deluxe Gig Bag
Recommended Case: Deluxe Stratocaster®/Telecaster® Molded Case, P/N 0996102306 (Not Included)
Saddle Height Wrench: .050" Hex (Allen) Wrench
Miscellaneous
Unique Features: Special Soft "V" Shape Neck, Fender®;/Schaller®; Straplock Strap Buttons, Middle Pickup is "Wide Open" With No Tone Control, Jimmy Vaughan Signature on Back of Headstock
